Poultry Lighting Bulbs D80
Product Brief
The D80 Poultry Lighting Bulb is engineered to provide a high-performance, stress-free lighting solution that supports healthy poultry growth while ensuring energy efficiency and ease of maintenance.
Features
1. Innovative Design: Provides optimal uniform light distribution, preventing chickens from clustering and promoting better movement.
2. Flicker-Free Dimming (0-100%): Smooth dimming function that eliminates flicker, reducing stress on chickens and improving overall well-being.
3. IP67 Rating: Fully waterproof and resistant to high-pressure washdowns, ensuring durability and reliability in tough environments.
4. Ammonia-Resistant PC Cover: Built to withstand harsh conditions, including exposure to ammonia in poultry houses.
5. Superior Heat Dissipation: Aluminum base design ensures excellent heat management for longer lifespan and optimal performance.
6. Easy Maintenance: Quick to clean and simple to install, minimizing. downtime and maximizing efficiency
7. Long-Lasting: 5-8 years warranty, guaranteeing the longevity and reliability of the product.
8. Certifications: CE, RoHS, UL, CB, CCC, ETL.
Applications
USE LIGHT TO IMPROVE YOUR ANIMAL WELFARE AND PRODUCTION.
Food Processing
Broilers Lighting
Ducks Lighting
Pigeons Lighting
Dimension
Specifications
Series
D80
Model No.
D80-10TD. D80-15TD. D80-15TD-WR. D80-7VD-48V. D80-9VD-48V. D80-10VD-48V. D80-12VD-48V.D80-15VD-48V
Dimension
⌀80*151.5mm
Input Power
10W. 15W. 10W+5W. 7W. 9W.10W.12W. 15W
Input Voltage
AC200-240V. DC48V
CCT
Customize different spectrums according to the animals, 3000K/4000K/5000K/6000K
Beam Angle
250°
Cover
Frosted
Lumen Efficiency
150lm/w(±5%)
Lumen(5000k)
AC_10W: ≧1206lm, AC_15W: ≧1790lm, AC_10+5W: ≧1206lm(5 years warranty）
DC_7W: ≧987lm, DC_9W: ≧1236lm, DC_10W: ≧1390lm, DC_12W: ≧1648lm, DC_15W: ≧1964lm
CRI
70/80
Surge Protection
2KV
Flicker(%)
Complies with ErP Energy Efficiency Certification, flicker-free Standard
Insulation Resistance
Class II
IP Rating
IP65
IK Rating
IK06
Hydrogen Sulfide Gas
168H,With electricity,40℃/90%RH,Concentration:15ppm
Ammonia
72H,30℃,Concentration:28%,Without electricity
Operation Temperature
-20℃~35℃@IP65 Indoor environment
Storage Temperature
-40℃~70℃@5~90% RH
Weight(NW)
0.35KG
Housing Material
PC+Aluminium alloy
LED Type And Numbers
3030 Ceramic: 10W/15W-28pcs LED(7 series*4 parallels),10+5W-41pcs LED(W:7 series*3 parallels),(R:20 series*1 parallels); 3030 Ceramic:7W/9W-24pcs LED(8 series*3 parallels) 10W/12W-32pcs LED(8 series*4 parallels),15W-32pcs LED(8 series*5 parallels)
Lifetime
70000H(L90B20@35℃)
Certificates
CE, RoHS, CB, CCC, UL, ETL
Control Modes And Data
Triac Dimming, 0/1-10V Dimming
